Technical Parameters |
Unit |
Parameter |
|
Reading Range |
GU |
0.0～199.9 |
|
Deviation |
GU |
±1.2 |
|
Resolution |
GU |
0.1 |
|
Measuring Area |
mm2 |
20×10 |
|
Power Supply |
V |
One AA-size battery |
|
Incidence Angle |
Deg. |
60 |
|
Volume(L×W×H) |
mm3 |
123×38×65 |
|
Main Weight |
g |
300 |
Applications：
- All kinds of coating and finishing surfaces, such as paints, varnishes, printing ink, etc.
- Decorative materials, such as marble, granite, polishing brick, ceramic tile and so on.
- The other kinds of materials and objects, such as plastic, woodenware, paper, etc.
Features：
- Small, Smart, Stable.
- Simple to use.
- A single battery only. AA size, Rechargeable or alkaline.
- The knob protector for operating with ease.
Service：
- Guaranteed for two years and repaired for ever.
- Anytime be checked free.
- Technical support on the gloss measurement.
- Customizing any glossmeter for a special application.
